Eos Skadi 200 RTK GNSS Receiver

ADVANCED GNSS RECEIVER FOR SURVEY-GRADE PRECISION IN ANY TERRAIN

The Skadi 200™ serves as the accessible foundation of Eos Positioning Systems’® Skadi Series™ RTK GNSS receivers. Equipped with dual-frequency support across all GNSS constellations, the Skadi 200 delivers consistent centimetre-precision RTK positioning for field applications. The receiver integrates seamlessly with any RTK network, CORS system, or base station configuration, while also utilizing free SBAS corrections in regions lacking RTK infrastructure. Its universal compatibility ensures operation with iOS®, Android™, and Windows® mobile platforms.

Beyond the standard precision and reliability found in all Eos GNSS products, the Skadi 200 features exclusive advanced mapping technologies specific to the Skadi Series lineup. These innovations include an integrated antenna system and interchangeable all-day battery design. The receiver supports optional Skadi Tilt Compensation™ activation, enabling continuous productivity by eliminating the need for range pole leveling at each measurement location.



Contact us for product pricing.

Categories: ,
Ports:Bluetooth, USB 2.0, Serial
GNSS Signals Received:GPS: L1CA, L1P, L2P, L2C
GLONASS: G1, G2, P1, P2
Galileo: E1BC, E5b
BeiDou: B1i, B2i, B2B
QZSS: L1CA, L1C, L2C
SBAS Support:
3 channel, parallel tracking (with SBAS ranging)
RTK Accuracy:8mm + 1ppm horizontal,
2cm + 1ppm vertical (RMS)
Bluetooth Transmission:Class 1 with 200m typical range
Compliance:FCC, CE, RoHS and Lead-free
Standard Accessories:Skadi 200 GNSS receiver with integrated antenna
Pole mounting plate for Skadi Series
Phone & Table mounting bracket for Skadi Series handles
Skadi Series Li-ion battery pack
USB-C cable & power adapter
Skadi Series hardshell case
Skadi Standard Handle
Battery:13+ hrs on a single charge (without tilt compensation)
11+ hours (with tilt compensation)
Enclosure Rating:Waterproof, IP-67
Weight:With battery: 610g (1.34 lbs)
With Skadi Standard Handle: 935g (2.06 lbs)
Dimensions:Receiver: 14.2cm x 9.5cm x 6cm (5.6″ x 3.7″ x 2.3″)
Skadi Standard Handle: 26.6.cm x 7.6cm x 16.2cm (10.5″ x 3.0″ x 6.4″)
Warranty:Skadi & Smart Handle: 2 year warranty
Battery & Accessories: 6 month warranty
